This manual aims to provide an overview of the features and functions of Monitor module that is part of ProMan project.

PM Monitor has the task of interfacing portable or fixed industrial terminals on which a state system is executed(configured with PM design module).


first,we analize the possible configurations of a data collection structure,so we clarify some of the terms that will be used to this manual and will be useful when explaining the PM Plant Editor,we define:

  • PC Host The PC on which the ProMan Monitor program will have installed. That computer will care to handle data collected from terminals and write it to the Database.
  • NetBox are the hardware and/or software that allow connection between PC Host and terminals.They are as collectors and information managers for the terminals connected to it.
  • Terminale: Any data collection device.



The previous scheme shows the configurations of a data collection plant that PM Monitor supports.We can see how most of the information passes over the local company network,reducing the need for dedicated wiring and increasing the flexibility of the installation.
